Nätverkstrafik 100Mbit/s och PoE i en vanlig antennkabel.
Håller du på att byta ut äldre övervakningskameror med koaxialkabel till IP-kameror? Och du har problem att byta ut kablaget.
Här har du lösningen!
Koppla sändaren i kamera-änden, den är så liten så den går ofta att montera in i kamerans "bas". Andra änden sätter du där kabeln slutar och pluggar den in i en PoE-switch eller en PoE-inserter så är du klar.
Den klarar upp till 500m koaxialkabel och 100m nätverkskabel i varje ände.
The xCOAX3-SET is a set of active converters for Ethernet data transmission and PoE power supply via coaxial cable which is often used in analog monitoring. The devices allow the installation of PoE IP cameras in places where the replacement of the existing coaxial cabling is impossible or uneconomical. The xCOAX3-SW module is powered from any PoE switch (RJ45 port) and through the coaxial cable, it enables bidirectional network communication and powering the xCOAX3-CAM module. The maximum length of the coaxial cable is 500m. A camera or other PoE receiver can be connected to the RJ45 port of the xCOAX-CAM module at the end of the line.
The BOX version (angled BNC connector arrangement) makes it easy to mount the xCOAX3-CAM-BOX module in a camera base or other installation box.
The polycarbonate casing is a well-thought-out solution ensuring isolation and the smallest possible size of the device. The compact size gives more installation options.
Key features:
- Transmission range over coaxial cable up to 500 m at 100 Mbps,
- Noise immunity and watchdog function in COAX path,
- Power supply from switch PoE 802.3at/af or PoE PASSIVE,
- Power supply to receiver PoE 802. 3at/af or PoE PASSIVE receivers
- up to 30W total power in the whole power path,
- Very low power consumption – 1,35 W,
- Compact modules,
- Clear, optical indication of power and data transmission status,
- Easy and quick startup without configuration of parameters.
Specifications
| Product | xCOAX3-SET-BOX |
| Code | J2840 |
| LAN ports | 1 RJ45 100Mbps port |
| Connectors | RJ-45 and BNC (female) |
| Port functions 1/2 | xCOAX3-SW: PoE INPUT (trunk power): PASSIVE (up to 30W), 802.3at (up to 30W), 802.3af (up to 15W) PoE PINS: 1.2 (V+/-) 3.6 (V+/-) and/or 4.5 (V+/-) 7.8 (V+/-) |
| Port functions 2/2 | xCOAX3-CAM-BOX: PoE OUTPUT (powering PoE receivers): PASSIVE (up to 30W), 802.3at (up to 30W), 802.3af (up to 15W) PoE PINS: 4.5 (V+) 7.8 (V-) |
| Operation indicator | LED RJ45 port (yellow) – power presence LED RJ45 port (green) – link and data transmission in LAN path LED at BNC connector (green) – link and data transmission in COAX path |
| Supply voltage | xCOAX3-SW: 44 ... 56 VDC |
| Output voltage | xCOAX3-CAM-BOX (for PoE devices): Vout = Vin (44 ... 56 VDC) |
| Power consumption | 1.35 W (entire path) |
| Coaxial cable length | < 500m – distance xCOAX3-SW to xCOAX3-CAM-BOX |
| Network cable length | < 100m – distance of PoE SWITCH to xCOAX-SW < 100m – distance of xCOAX3-CAM-BOX to CAMERA |
| Protection | LAN and BNC ports: Overvoltage protection xCOAX3-SW: 0.7 A short circuit protection with auto-recovery |
| Enclosure design | Polycarbonate |
| Protection degree | IP20 |
| Operating temperature | -25°C...+65°C |
| Dimensions | xCOAX3-SW - 106 x 24 x 21.5 mm xCOAX3-CAM-BOX - 90 x 35 x 21.5 mm |
| Weight | xCOAX3-SW – 0.03 kg xCOAX3-CAM-BOX - 0.03 kg |
