CYP/// Styrbox över IP med 6 knappar, passar EURO dosor

4 900 kr



CR-KP3

CR-KP3 är ett minimalistiskt styrsystem för vägg-montering som kan strömförsörjas antingen genom PoE eller en separat nätdel direkt till enheten.


CR-KP3 har även en schemaläggnings funktion där man kan programmera macron att köras vid fördefinierade tider, t.ex. att stänga av alla prylar efter dagens slut.


CR-KP3 kan programmeras genom Web GUI:t som du lätt kan nå genom en vanlig webbläsare.


The CR-KP3 Wall Plate Control System Keypads are versatile and useful products for both system integrators and smart home users alike. These keypads can send commands to any Ethernet controlled device in your system.

With 6 direct macro buttons (plus an additional 6 macros within the WebGUI control) which allows up to 16 commands to be executed within one button press, and a total of up to 128 commands capacity within the unit, this keypad can activate a set of command scenarios in a seconds. The soft and colorful LED buttons are suitable for all environments and PoE (Power over Ethernet) support allows for creative placement of the keypad within your space without concern for location near to a power source.

Additionally, the integrated clock and calendar based scheduling feature allows you to trigger macros to control devices within your installation at a specific time, or on a recurring schedule.

Features:


6 direct macro keys for controlling user equipment
Up to 128 total commands can be stored and used across all macros in the system (up to 16 per macro)
Supports relay triggers to control compatible devices
Supports time and date macro scheduling (single and recurring)
Supports one month of backup power for the internal clock and schedule function to protect against power blackouts and temporary power loss
Supports customizable daylight savings time for scheduling
Supports Keypad, Telnet and WebGUI control
Supports PoE or DC power supply
Multiple uses for home, hotel rooms, central control rooms, conference room applications

Specification:


Input:1x RJ45 [1x (supports PoE) LAN Serving]
Output:1x Phoenix (2 pin) [1x Contact Closure Relay Outputs]


PoE PSU:PoE
PSU:5V/2.6A
Dimensions:88mm [W] x 88mm [D] x 37mm [H]
Net. Weight:156g
Gross Weight:530g
