CYP/// UHD+ HDMI over HDBaseT 3.0 Receiver (18Gbps, 4K@60Hz 4:4:4, 8-bit)

8 250 kr



PUV-3000RX

The PUV-3000RX Receiver is part of a new generation of HDBaseT 3.0 technology and supports up to 4K UHD+ (18Gbps, 4K@60Hz 4:4:4, 8-bit) video over HDBaseT.

This is a great solution for extending uncompressed HDMI 2.0 4K@60 (4:4:4, 8-bit) video, as well as control, via a single run of Cat.6a/7 cable over distances of up to 40 meters. Multiple control and data signals may also be transmitted along with the video/audio, including IR and RS-232.

This Receiver is ideal for any scenario which needs uncompressed video, such as medical equipment, conference rooms, education and residential applications.

Compatible Transmitter required.

Features:

  • Supports up to 4K UHD+ (18Gbps, 4K@60Hz 4:4:4, 8-bit) video over HDBaseT.
  • HDMI 2.0 and DVI 1.0 compatible, HDCP 2.2 and HDCP 1.x compliant
  • HDBaseT 3.0 compliant (Backwards compatible with HDBaseT 2.0/1.0)
  • Supports Deep Color input and output up to 12-bit
  • Supports 10-bit and 12-bit HDR (High Dynamic Range) input/output
  • Supports providing PoH power from Transmitter to Receiver in same HDBaseT port

Specifications:

Inputs1x HDMI [1x HDMI local input Uncompressed AV and Data]
1x RJ45 [1x HDBaseT3 HDMI & Propriety Data]
1x USB Micro [1x USB Service Port Propriety Data]
1x Phoenix (4 pin) [1x Shared IR I/O]

Outputs1x HDMI [1x HDMI Uncompressed AV and Data]
1x Phoenix (4 pin) [1x Shared IR I/O]
1x Phoenix (4 pin) [1x RS-232 HDBaseT pathway]


POE PSU:PoH
Dimensions128mm [W] x 109mm [D] x 25mm [H]
Net Weight390g
Gross Weight740g
