PRO-3GSDIHDMI
The PRO-3GSDIHDMI Extender with HDMI Scaler allows SD-SDI, HD-SDI, and 3G-SDI signals to be displayed on HDMI or SDI screens. These signals can be extended over long distances using the SDI "loop-though" facility which equalises and re-clocks the signal each time it is cascaded, whilst simultaneously outputting the source signal via the HDMI output.Features
Operation at 2.970Gb/s, 2.970/1.001Gb/s, 1.485Gb/s, 1.485/1.001Gb/s and 270Mb/s
Supports SMPTE 425M (Level A and Level B), SMPTE 424M, SMPTE 292M, SMPTE 259M-C
Equalized and re-clocked loop output
Dual audio outputs: coaxial and analogue stereo
Integrated audio de-embedder for a maximum of 8 channels of 48kHz audio
Auto video mode detection (3G/SD/HD)
Conversion from SMPTE 425M level B to Level A for 1080p 50/59.94/60 4:2:2 10-bit
Video Support: SD - 480i, 576i: HD - 720p 50/60, 1080i 50/60, 1080p 24/25/30: 3G - 1080p 50/60
Frequency Bandwidth - 225MHz (HDMI 1.3)
Supports SDI signal distance up to 300m for SD signal, 200m for HD signal and 100m for 3G signals
Supplied with Locking PSU
Specification
Inputs 1x BNC [1x SD-SDI / HD-SDI / 3G-SDI]
Outputs 1x HDMI [1x HDMI Uncompressed AV and Data], 2x RCA [1x Analogue Stereo (L/R)], 1x BNC [1x Loop Output SD-SDI / HD-SDI / 3G-SDI], 1x RCA [1x Coaxial 2 Channel LPCM]
Power 5V/2.6A, DC (US/EU standards, CE/FCC/UL certified)
Dimensions 180mm (W) x 140mm (D) x 25mm (H)
Gross Weight 880g
Net. Weight 640g
