CYP/// HDMI-HDBaseT 4X8 Matris med PoE och LAN

Produkten är tyvärr slut i lager. :(


CYP/// PU-444HBTE är en HDMI till HDBaseT Matrix med 4 HDMI in, 4 HDBaseT ut och dessutom 4 vanliga HDMI ut, alltså en 4x8. Den klarar att skicka HDMI, IR, RS232, PoE och Ethernet-trafik upp till 100m i en vanlig nätverkskabel.

Styr den gör man antingen med knappar på fronten, fjärrkontroll, Extern IR-styrning, RS232 elller IP.

The PU-444HBTE Matrix enables distribution of four HDMI sources to four HDBaseT outputs and four HDMI outputs. Each input is independently routed to any output for maximum source to screen flexibility within any AV system. The four HDBaseT outputs support the transmission of video (resolutions up to 1080p Full HD and [email protected]), multi-channel audio, single LAN serving, and control via 2-way IR, RS-232 or Web GUI/Telnet IP over a single CAT5e/6/7 cable (up to 100m) for each output. HDMI outputs support the same video resolutions and high definition audio via certified HDMI cables up to 15m.

The HDBaseT outputs are designed to be used with any compatible HDBaseT Receiver as follows: PU-507RX / PU-507RX-2H / PU-507RX-SCD / PU-507WPRX / PU-1109RX. These Receivers support Power over Ethernet (PoE) function so do not require a separate PSU for power.

Use the LAN serving capabilities of the matrix to add internet connectivity to every HDBaseT output zone. In addition, this matrix also features IP control allowing users to access and control the matrix remotely and also allow additional options for integration of third-party control systems such as Demopad.


HDMI, HDCP and DVI complaint
Common supported resolutions : HDTV: 480p, 576p, 720p, 1080i, 1080p, 1080p24: PC: VGA, SVGA, XGA, WXGA, SXGA, UXGA, WUXGA, [email protected]
High Definition Audio supported : Dolby TrueHD, Dolby Digital Plus and DTS-HD Master Audio plus LPCM (up to 192kHz)
Uncompressed data transfer over single CAT cable for HDBaseT outputs (100m - CAT6/7: 80m - CAT5e)
Supports HDMI input up to 15m 1080p 8bit or 10m 1080p 12bit.
Supports RS-232, 2-Way IR, Manual Selection Buttons, and Web GUI/Telnet IP for control
HDBaseT outputs support Power over Ethernet (PoE) with compatible receiver units
Selectable EDID settings - TV (downstream) and STD (fixed)
Supports LAN serving to all connected HDBaseT zones
Supports 3D signals


4x HDMI [4x HDMI Uncompressed AV and Data]
1x 9pin Dsub [1x RS-232 Data]
1x RJ45 [1x IP Control / LAN Serving]
1x USB Mini B [1x Service Port Propriety Data]
5x 3.5mm Stereo mini-jack [5x Infra Red Receiver]
Outputs4x HDMI [4x HDMI Uncompressed AV and Data]
4x RJ45 [4x HDBaseT HDMI & Propriety Data]
5x 3.5mm Stereo mini-jack [5x Infra Red Emitter]

Dimensions:430mm [W] x 250mm [D] x 50mm [H]
Net Weight:3320g
Gross Weight4600g
