PU-507TX-CVGA
PU-507TX-CVGA är en HDBaseT sändare som gör det möjligt att skicka PC eller Komposit video källor och ljud över en enkel Cat5e/6/7 kabel till en mottagare upp till 100 meter bort. Den integrerade scalern gör det möjligt för installatören att maximera utgångs upplösningen och säkerställa kompatibiliteten till skärmen.Den här sändaren stödjer transport av LAN trafik, Bi-Directional Power over Ethernet ( PoE ), RS-232, 2 vägs IR och okomprimerad transport av video och ljud.
Styrning av sändaren kan uppnås genom IR fjärrstyrning eller via knapparna på fronten som visar en On-Screen Display (OSD) för enkel navigation på den inkopplade skärmen.
?The PU-507TX-CVGA is a HDBaseT™ Transmitter which allows transmission of PC or Composite Video sources and audio over a single CAT5e/6/7 cable to the receiver at a distance of up to 100m. The integrated scaler enables the installer to maximise the output resolution and ensure compatibility to the connected display. With full 5-Play convergence for uncompressed high definition video and stereo audio, this transmitter also allows the transfer of LAN serving, Bi-directional Power over Ethernet (PoE), RS-232, and 2-way IR all simultaneously over a single CAT5e/6/7 cable. Control of the transmitter is via IR remote or via selection buttons on the front panel of the device allowing the user to navigate the On-Screen Display (OSD) for selecting the required settings or system information.
Features:
Supports PC/CV scaling to a full range of HDTV or PC resolutions up to 1080p and WUXGA (Reduced Blanking)
Supports uncompressed video/audio up to 10.2Gbps
Supports Ethernet transmission rates up to 100 Mbps
Supports uncompressed data transfer over single CAT cable (100m - CAT6/7: 80m - CAT5e)
5-Play™ convergence: HDMI, LAN, POE & Control (IR & RS232)
Supports bi-directional PoE when connected to a compatible Bi-directional PoE Receiver
Supports OSD (On-screen Display) selection and system information display
Supports NTSC and PAL formats for Composite Video input
Control via IR remote and on-panel selection buttons
Specification:
Input:
1x 15pin Dsub [1x PC RGBHV]
1x RCA [1x Composite]
1x 3.5mm Stereo mini-jack [1x Analogue Stereo(L/R)]
1x 3.5mm Stereo mini-jack [1x Infra Red Receiver]
1x 9pin Dsub [1x RS-232 Data]
1x USB Type A [1x Service Port Propriety Data]
1x RJ45 [1x LAN Serving]
Outputs:
1x RJ45 [1x HDBaseT HDMI & Propriety Data]
1x 3.5mm Stereo mini-jack [1x Infra Red Emitter]
PSU: 24V/2.7A
Dimensions: 145mm [W] x 200mm [D] x 35mm [H]
Net Weight: 600g
Gross Weight: 1200g
