CYP/// HDMI audio de-embedder, 5.1 ljud, 4K, HDCP 2.2, HDMI 2.0

4 200 kr



AU-11CD-4K22

AU-11CD-4K22 är en de-embedder för ljud. Man matar in en kombinerad bild & ljud signal genom en HDMI kontakt och kan sedan plocka ut en orörd HDMI signal plus optiskt digitalt eller analogt ( 2xRCA ) ljud vid sidan om.


Denna kan med fördel användas för att plocka ut ljudet från till exempel en AppleTV 4 för att skickas in i en soundbar eller liknande.


Det är bara att koppla in AU-11CD-4K22 mellan källan och skärmen via HDMI och välja vilket ljudformat som skall användas.



The AU-11CD-4K22 is an advanced solution for repeating HDMI with integrated Audio de-embedding, up to 5.1. Connect the AU-11CD-4K22 between your source and display via HDMI, and select the audio format required. This device supports 4K resolutions, HDMI 2.0 and HDCP 2.2 enabling flexible audio signal management from ultra high definition video signal paths. The built-in HDMI repeater function allows users to extend the transmission distance of up to [email protected] resolutions a further 5m from the device HDMI output.

Features:


HDMI2.0, HDCP 2.2, and DVI compliant
Supports HDTV resolutions up to 4Kx2K ([email protected]/25/30/ 50/60 YUV_444 & [email protected]/25/30/50/60 YUV_444).
Supports bypass of high resolution digital audio formats including LPCM 7.1CH, Dolby TrueHD, Dolby Digital Plus, Dolby Atmos and DTS-HD Master Audio
Supports HDMI audio sampling rate up to 192 kHz
Supports Optical S/PDIF audio sampling rate up to 192 kHz
Supports external HDMI, Digital or Analog audio signal embeds into HDMI
HDMI supports high-bit-rate (HBR) audio
Supports DVI conversion with HDMI to DVI adaptor
Supports CEC bypass
Supports analog stereo L/R and Optical S/PDIF audio outputs

Specification:


Input:1x HDMI [1x HDMI 2.0 Uncompressed AV and Data]
Output:1x HDMI [1x HDMI 2.0 Uncompressed AV and Data]
1x Toslink [1x Optical 2 Channel LPCM]
2x RCA [1x Analogue audio Stereo (L/R)]
 : :
PSU:5V/2.6A
Dimensions:128mm [W] x 117mm [D] x 30mm [H]
Net. Weight:358g
Gross Weight:595g
