CYP/// HDMI 4 in 2 ut v 1.3

3 750 kr



EL-42S

En äkta 4 till 2 med HDMI v1.3 i välkänd CYP-kvalitet.


The EL-42S switcher allows the user to input four HDMI sources and switch between these sources to display HD content on 2 displays. This switcher can be controlled via the supplied remote control, RS-232, or by using the input switching button on the front of the device.

Features:

  • v1.3 HDMI, HDCP 1.1 and DVI 1.0 compliant
  • HDMI 4 Way Switcher with 2 Identical Outputs
  • Resolutions Supported: PC - VGA, SVGA, XGA, SXGA, UXGA & WUXGA (1920x1200). HDTV - 480i, 576i, 480p, 576p, 720p, 1080i, 1080p and 1080p24fps
  • High Definition Audio supported - Dolby TrueHD, Dolby Digital Plus and DTS-HD Master Audio plus LPCM
  • Auto signal enhancement feature can improve signal quality after long distance transmission
  • RS232 & IR Remote Control
  • Supports 'Deep Colour' (10 & 12 bit)
  • Dual HDMI outputs for simultanious connection to two HD Displays
  • Supports 3D signals
  • Supports xvYCC

Specifications:

Inputs4x HDMI [4x HDMI Uncompressed AV and Data]
Outputs2x HDMI [2x HDMI Uncompressed AV and Data]
PSU:5V/2.6A
Dimensions240mm [W] x 104mm [D] x 50mm [H]
Net Weight600g
Gross Weight820g


En HDMI Switch används för att utöka antalet INGÅNGAR i en installation, om du vill öka antalet UTGÅNGAR skall du istället välja en HDMI Splitter!


Tänk också på att all utrustning där du skall låta dina signaler passera påverkar din bildkvalitet, välj HDMI splitter eller HDMI switch med omsorg från en välkänd tillverkare och leverantör för att säkerställa den fina bildkvalitet som HDMI kan erbjuda.
