CYP/// Slimline HDBaseT 2.0 KIT, 4K, HDCP 2.2, PoH, USB

18 400 kr



PUV-2010-KIT

Här har vi ett Slimline KIT för att skicka HDMI, USB, LAN och ström till mottagaren. Med stöd för HDBaseT 2.0, HDCP 2.2, OAR upp till 100 meter.


Kittet består av:

1 st Slimline HDBaseT 2.0 Sändare

1 st Slimline HDBaseT 2.0 Mottagare


Mer info finns på respektive artikel.


Features:


Supports full HDBaseT™ 2.0 specification signals can be received up to a maximum distance of 100m over CAT6a/7
HDCP 2.2, HDMI and DVI compatible
HDBaseT 5-Play™ convergence: High-Definition video and audio, 100BaseT Ethernet, PoH (Power over HDBaseT) and control (Bi-Directional IR & RS-232 pass through)
Supported resolutions VGA~WUXGA, 480i~1080p, 4K [email protected]/25/30Hz (RGB 4:4:4 & YUV 4:2:2), 4K [email protected] 60Hz (YUV 4:2:0), 4K/[email protected]/25/30Hz (RGB 4:4:4 & YUV 4:2:2) and 4K/[email protected] 60Hz (YUV 4:2:0) dependent upon the output display’s EDID settings
4K/2K & 4K UHD signals can be transmitted up to 70m via CAT5e/6 and 100m via CAT6a/7
Supports pass-through of HD audio formats: LPCM 2/5.1/7.1CH, Dolby Digital 2/5.1CH, Dolby Digital Plus, Dolby TrueHD, Dolby Atmos and DTS-HD Master Audio
Optical audio return (OAR)
Supports optical sampling rate up to 48kHz
Audio return channel (ARC)
Dedicated channel for analogue stereo audio transmission from the transmitter to a compatible receiver.
Ultra slim chassis design for ease of installation
USB Data Serving from Transmitter (single USB) to Receiver (2x USB).
